Strong Stability IPAC-CS Panasonic SMT Equipment Mounter Stretchable

IPAC - CS Panasonic IPAC high-speed placement machine SMT processing mobile digital consumer electronics:

Panasonic SMT machine IPAC - CS main parameters:

PCB size: 323 x 146 mm

The patch speed: 0.1 SEC

Patch: accuracy + / - 0.05 mm

The patch stance: 48

Capacity assessment

Element range: 0201-24 mm QFP, PLCC, SOP, BGA, etc

Theory: 36000 components per hour

Actual: about 25200 components per hour

Equipment size: 980 * 1660 * 1650 mm

Suitable for SMT products

SMT processing, MID, mobile phones, digital and consumer electronics.

Service commitment:

1, happy to provide you with comprehensive training, to ensure that customers fully understand our equipment.
2, willing to share with you the latest technology, and combined with your product needs, provide a full range of solutions.
3, you also don't have to worry about the supply of parts, we have a lot of equipment to introduce you to the original or copy of parts.

4, we have a group of outstanding service engineer 24 hours waiting for your call.

A device solutions

A device can also be started producing high versatility

Live-fire chip tray component, only one device can be completed

> < fixed supply department specifications, reduce the investment cost

Connected to the existing CM/NPM equipment, strengthen the universality and versatility of the production line

High ratio of general production line

The best equilibrium line commonality cost, actual productivity

Implement equipment through 14 suction nozzle head equilibrium between low loss and high operation

According to the demand, can choose the best of the specifications of the supply department

Corresponding (chuck clamping type suction nozzle size can be changed)

A variety of small amounts of production solutions

Support many kinds of the choose and buy of a small amount of production of the height of the actual productivity

Common use of components of carrying capacity, arrange the plural varieties (MJS *)

Through the support pin to replace function, support the preparation

Started production, to ensure the quality of live-fire: camera / 3 d sensor chip thickness

* MJS: this is the data into system (NPM - DGS) function.

A cutting-edge process line

Through a combination of choose and buy, can also correspond to cutting-edge technology

PoP live-fire: universal transfer unit

Sheet base slabs should be: height sensor (base plate bending measurement)

MPM printing machine, Koh Young SPI, Easa reflow soldering, HELLER reflow
